Z28-650 Type Thread Rolling Machine

Z28-650 type thread rolling machine, product features: The machine is structurally strong, well-made and powerful. It is mainly used for rolling various large trapezoidal threads, modular threads and high-strength standard parts. Suitable for rolling materials with a material elongation of more than 10% and tensile strength less than 100N/m2 for various carbon steels, alloy steels and non-ferrous metals.

Category:

Two Axis Thread Rolling Machine Series

Inquiry

Description

产品描述

Products Name:Z28-650 Type Thread Rolling Machine

Technical Parameters:

Maximum Rolling Force	650KN		Thread Length	No Limits (Additional Protection)
Diameter	Radial feed	Φ120mm	Spindle Speed	16、26、38、 55、90（r/min）
Diameter	Axial feed	Φ120mm	Spindle Speed	16、26、38、 55、90（r/min）
Roller diameter	The maximum diameter	Φ290mm	Active forceActive force	22kw
	Inner diameter	Φ100mm	Hydraulic Power	7.5kw
	Maximum thickness	200mm	Cooling Power	0.125kw
Spindle Inclination Angle	±15°		Dimensions	2500×2700×3100mm
Spindle center distance	300-410mm		Electrical Cabinet Size	800×500×1250mm
Weight	6100kg±50kg
