850 Type Wire Drawing Machine

Product Name:850Type Wire Drawing Machine Product features: The machine adopts frequency conversion control, high automation, can draw high, medium and low carbon wire with diameter of less than 18 mm, non-ferrous metal wire, has the characteristics of high drawing speed, and is the preferred equipment for screw manufacturers.

Category:

Wire Drawing Machine Series

Inquiry
Related

Description

  • 产品描述

  • Product Name: 850 Type Wire Drawing Machine

    Technical Parameters:

    Motor Power

    37-45kw

    Speed Adjustment Mode

    Frequency Converter Stepless Speed Adjustment

    Winding Drum Diameter

    1200mm

    Line Winding Way

    Active/Passive

    Maximum Inlet Wire Diameter

    16mm

    Line Winding Weight

    2000kg

    Line Speed

    60m/min

    Weight

    5500kg

    Pulling Strength

    5-30mpa

    Dimensions

    4700×1800×2900mm


    Electrical Cabinet Size

    700×500×1250mm
