Z28-200 Type Thread Rolling Machine

Product Features: Z28-200 type thread rolling machine is mainly used for rolling a variety of specifications of building through-wall wire, jacking, trapezoidal thread and modulus thread workpiece and has the features of simple operation and high efficiency.

Category:

Two Axis Thread Rolling Machine Series

Inquiry
Related

Description

  • 产品描述

  • Product Name: Z28-200 Type Thread Rolling Machine

    Technical Parameters:

    Max roll pressure

    200KN

    Thread Length

    No Limit (Additional Protection)

    Diameter

    Radial feed

    Φ60mm

    Spindle speed

    16、26、38、

    55、90（r/min）

    Axial feed

    Φ52mm

    Roller diameter

    The maximum diameter

    Φ210mm

    Active force

    11kw

    Aperture

    Φ75mm

    Hydraulic Power

    4kw

    Maximum thickness

    120mm

    Cooling Power

    125w

    Spindle inclination angle

    ±15°

    Total Weight

    2300kg±50kg

    Spindle center distance

    150-270mm

    Dimensions

    1700×1850×1550mm
