ZC28-6.3 Type Three rollers Thread Rolling Machine

Product

ZC28-6.3 Type Three rollers Thread Rolling Machine

ZC28-6.3 three-axis thread-rolling machine, product characteristics: This machine is a kind of equipment which uses metal to produce plastic deformation under pressure. It uses three roller wheels with 120 degrees angle to process workpiece threads. It is especially suitable for rolling thin-walled workpieces and other heterosexual workpieces.
产品描述

Product Name:ZC28-6.3 Type Tri-axial Thread Rolling Machinep>

Technical Parameters:



Maximum Rolling Force

150KN

Wall thickness of the Processing Workpiece

Not less than 2mm

Rolling Material Diameter

Φ30-Φ80mm

No Thread Length Limits

No Limits (Additional Protection)

Roller outer Diameter

Φ120-Φ170mm

Active forceActive force

5.5kw

Roller inner Diameter

Φ54mm

Hydraulic Power

4kw

Maximum Roller Thickness

100mm

Cooling Power

125w

Spindle Inclination Angle

±3°

Weight

1900kg±50kg

Active Spindle Feed Rate

20mm/s

Dimensions

1750×1600×1900mm



Electrical Cabinet Size

750×450×1100mm
