ZC28-40 Type Three-axle Thread Rolling Machine

Product

ZC28-40 Type Three-axle Thread Rolling Machine

ZC28-40 three-axis thread rolling machine product characteristics: this machine is specially designed for pipe parts, to ensure the true roundness, concentricity and verticality of the workpiece when hobbing teeth with equal triangle support; fixed rolling dual-purpose, spindle using frequency converter control, speed adjustable, feed using oil-piezoelectric circuit control, feed stable, simple operation; transmission gear grinding after heat treatment, machine noise is small, durable It is suitable for machine, bicycle, auto parts and tubing joint industries.
产品描述

Product Name: ZC28-40 Type Three-axle Thread Rolling Machine

Technical Parameters:



Screw Diameter

Φ9-40mm

Roller Wheel Shaft Stroke Interval

90-55mm

Pitch Range

0.5P-2.5P

Rolling Amount

4-25

Rolling Length

Fixed/ Idler Wheel (length is unlimited) Dual-purpose

Roller Shaft Angle

±3°

Roller Wheel Revolutions

350、600r.p.m

Roller Wheel Shaft Horsepower

2HP(1.5kw)

Outer Diameter of roller

Φ78mm(90mm)

Hydraulic Horsepower

2HP(1.5kw)

Inner Diameter of roller

Φ35

Weight

600kg

Thickness of roller

20、40mm

Dimensions

1200×850×1400mm
