Z28-250 Type Thread Rolling Machine

Product

Z28-250 Type Thread Rolling Machine

Product Features: Z28-250 type thread rolling machine is mainly used for rolling a variety of specifications of precision external thread and high-strength standard parts, including plain thread, trapezoid thread and modulus thread.

产品描述

Z28-250 Type Thread Rolling Machine

Technical Parameters:

Maximum Rolling pressure	260KN		Thread length	No Limit (Additional Protection)
Maximum Diameter	Radial feed	Φ90mm	Spindle Speed	16、26、38、 55、90（r/min）
Maximum Diameter	Axial feed	Φ60mm	Spindle Speed	16、26、38、 55、90（r/min）
Roller diameter	The maximum diameter	Φ210mm	Active Force	15kw
	Aperture	Φ75mm	Hydraulic Power	5.5kw
	Maximum thickness	120mm	Cooling Power	125w
Spindle inclination angle	±15°		Dimensions	1950×1750×1600mm
Spindle center distance	150-300mm		Total Weight	3000kg±50kg
